3 speeds
Three different speeds to set the air flow at the correct level according to your needs.
Diameter of air outlet (mm)150
Noise level (dB(A) re 1 pW)63
Min./Max. extraction rate (m3/hr)298
Aluminium filter
Aluminium filter guarantee better durability and performance.
Technical Specifications
MAIN FEATURES
- Model
- CCE19/2X
- Product code
- 36900441
- EAN Code
- 8016361854857
- Installation type
- Wall-mounted
- Typology
- Freestanding Wall Decorative
TECHNICAL FEATURES
- Connectivity
- None
- Frequency (Hz)
- 50/60
- IoT App
- None
- Grease filter type
- Multilayer cassette
- Total power of the lamps (W)
- 56
- Type of control
- Mechanical
- Number of motors
- 1
- Type of lamps used
- Halogen
- Voltage (V)
- 220-240
PROGRAMMES AND FUNCTIONS
- Number of speed settings
- 3
AESTHETIC
- Colour
- Stainless Steel
- Material body
- stainless steel
PERFORMANCE
- Min./Max. extraction rate (m3/hr)
- 298
- Energy Efficiency class (2010/30/EC)
- D
- Noise level (dB(A) re 1 pW)
- 63
- Power (W)
- <1000 W
DIMENSIONS
- Height of product without chimney (mm)
- 560
- Diameter of air outlet (mm)
- 150
- Height of the product (mm)
- 573
- Width of the product (mm)
- 900
- Depth of the product (mm)
- 480
- Packaged Product Height (mm)
- 540
- Width of the packed product (mm)
- 950
- Packaged Product Depth(mm)
- 245
- Gross weight (kg)
- 9.8
- Net weight (kg)
- 8.3
