3 speeds
Three different speeds to set the air flow at the correct level according to your needs.
Diameter of air outlet (mm)120
Noise level (dB(A) re 1 pW)70
Min./Max. extraction rate (m3/hr)335
Technical Specifications
MAIN FEATURES
- Model
- CSD6MX
- Product code
- 36901847
- EAN Code
- 8059019059570
- Installation type
- Built-in
- Typology
- Standard
TECHNICAL FEATURES
- Connectivity
- None
- Frequency (Hz)
- 50/60
- IoT App
- None
- Grease filter type
- Multilayer
- Total power of the lamps (W)
- 2
- Type of control
- Mechanical
- Number of motors
- 2
- Type of lamps used
- LED
- Voltage (V)
- 220-240
PROGRAMMES AND FUNCTIONS
- Number of speed settings
- 3
AESTHETIC
- Colour
- Stainless Steel
- Material body
- STAINLESS STEEL
PERFORMANCE
- Min./Max. extraction rate (m3/hr)
- 335
- Energy Efficiency class (2010/30/EC)
- E
- Noise level (dB(A) re 1 pW)
- 70
- Power (W)
- <1000 W
DIMENSIONS
- Height of the chimney (mm)
- 0
- Height of product without chimney (mm)
- 100
- Diameter of air outlet (mm)
- 120
- Height of the product (mm)
- 100
- Width of the product (mm)
- 596
- Depth of the product (mm)
- 496
- Packaged Product Height (mm)
- 560
- Width of the packed product (mm)
- 650
- Packaged Product Depth(mm)
- 160
- Gross weight (kg)
- 5.7
- Net weight (kg)
- 5.1
