Aluminium filter
Aluminium filter guarantee better durability and performance.
Diameter of air outlet (mm)-
Noise level (dB(A) re 1 pW)67
Min./Max. extraction rate (m3/hr)440
Technical Specifications
MAIN FEATURES
- Model
- CBT9240/4XX
- Product code
- 36901612
- EAN Code
- 8059019014876
- Installation type
- Wall-mounted
- Typology
- Built-in/Telescopic
TECHNICAL FEATURES
- Connectivity
- None
- Frequency (Hz)
- 50/60
- IoT App
- None
- Grease filter type
- Multilayer
- Total power of the lamps (W)
- 2.5
- Type of control
- Rocker
- Number of motors
- 2
- Type of lamps used
- Halogen
- Voltage (V)
- 220-240
PROGRAMMES AND FUNCTIONS
- Number of speed settings
- 2
AESTHETIC
- Colour
- White
- Material body
- white + squared stainless steel frontal with details inox
PERFORMANCE
- Min./Max. extraction rate (m3/hr)
- 440
- Energy Efficiency class (2010/30/EC)
- E
- Noise level (dB(A) re 1 pW)
- 67
- Power (W)
- UNDEFINED
DIMENSIONS
- Height of product without chimney (mm)
- 200
- Height of the product (mm)
- 200
- Width of the product (mm)
- 898
- Depth of the product (mm)
- 298
- Packaged Product Height (mm)
- 360
- Width of the packed product (mm)
- 945
- Packaged Product Depth(mm)
- 225
- Gross weight (kg)
- 10.5
- Net weight (kg)
- 9
